Home
>
Bookshelf Speakers
>
Wilson Benesch
>
Wilson Benesch ARC
Wilson Benesch arc
36
views this month
Posted On
28.01.2026
Last Update On
28.01.2026
Description
Original Description is in
Turkish
, other language texts are translations and can contain errors.
English
Deutsch
Spanish
Turkish
It is technically and cosmetically problem-free.
We are waiting for you at Timpani Audio for the demo.
Specifications
2-way, true linear-phase, free-space, bass-reflex cabinet, floor-standing monitor
Driver units: 1 x 170 mm (7 in) Wilson Benesch Tactic bass/mid frequency unit and 1 x 25 mm (1 in) soft-domed, hand-painted silk, ultra-linear Wilson Benesch spec treble speaker.
Low-frequency upload: Dual reflex port
Frequency range: -6 dB at 42 Hz and 30 kHz and -3 dB
at 45 Hz and 25 kHz Frequency response: 46 Hz to 24 kHz +- 2 dB on axis
Sensitivity: 88 dB SPL at a distance of 1 meter on the axis. 2.83 V input voltage.
Impedance: Nominal 6 Ohms, minimum 4 Ohm
Crossover: First-order mid-frequency crossover, second-order treble crossover, selected polypropylene capacitors and air-core inductors are used in the entire circuit.
Crossover frequencies 5kHz
Internal wiring: Multi-wire, silver-plated copper, PTFE sheathed wiring harnesses. All connections are soldered. Short path PCB design. Connections are provided for single or twin-wire applications.
Input connections: Dual-wired, in-house machined gold-plated copper alloy terminals
200W peak power capacity
in non-stop program Maximum SPL 111 dB at a distance of 1 meter.
Dimensions: HeightWidthDepth: 310 mm, 230 mm, 370 mm, Height with foot: 950 mm
Internal volume: 10.5 liters
Weight: 10 kg (20 kg with footrest)
Technisch und kosmetisch ist es problemlos.
Wir warten auf Sie bei Timpani Audio für die Demo.
Technische Daten
2-Wege, echte lineare Phase, Freiraum, Bassreflex-Box, bodenstehender Monitor
Treibereinheiten: 1 x 170 mm Wilson Benesch Tactic Bass-/Mittelfrequenzeinheit und 1 x 25 mm (1 Zoll) weichkuppelförmiger, handbemalter Seidenlautsprecher ultralinearer Wilson Benesch Spec Diskantlautsprecher.
Niederfrequenz-Upload: Dual-Reflex-Port
Frequenzbereich: -6 dB bei 42 Hz und 30 kHz sowie -3 dB
bei 45 Hz und 25 kHz Frequenzgang: 46 Hz bis 24 kHz +-2 dB auf der Achse
Empfindlichkeit: 88 dB SPL in einem Abstand von 1 Meter auf der Achse. 2,83 V Eingangsspannung.
Impedanz: Nominale 6 Ohm, minimale 4 Ohm
Weichweiche: Erstordnungs-Mittelfrequenz-Weichweiche, zweite Ordnung Diskant-Frequenzweiche, ausgewählte Polypropylen-Kondensatoren und Luftkern-Induktoren werden in der gesamten Schaltung verwendet.
Frequenzweichenfrequenzen 5 kHz
Interne Verkabelung: Mehradrige, versilberte Kupfer, PTFE-ummantelte Kabelbäume. Alle Verbindungen sind gelötet. Kurzweg-PCB-Design. Anschlüsse sind für Ein- oder Zwillingsdrahtanwendungen vorgesehen.
Eingangsverbindungen: Doppeldrahtige, hauseigene Anschlüsse aus vergoldeter Kupferlegierung mit
200W Spitzenleistung
im ununterbrochenen Programm, maximale SPL 111 dB in einer Entfernung von 1 Meter.
Abmessungen: Höhe Breite Tiefe: 310 mm, 230 mm, 370 mm, Höhe mit Fuß: 950 mm
Innenvolumen: 10,5 Liter
Gewicht: 10 kg (20 kg mit Fußstütze)
Es técnica y cosméticamente libre de problemas.
Te esperamos en Timpani Audio para la demo.
Especificaciones
Caja de 2 vías, verdadera fase lineal, espacio libre, bajo-réflex, monitor
de suelo Unidades de controlador: 1 unidad Wilson Benesch Tactic de 170 mm (7 pulgadas) para graves/frecuencias medias y 1 altavoz de 25 mm (1 pulgada) de seda pintada a mano, con domo blando, ultralineal y especificaciones Wilson Benesch de especificación ultralineal.
Subida de baja frecuencia: puerto
réflex dual Rango de frecuencia: -6 dB a 42 Hz y 30 kHz y -3 dB
a 45 Hz y 25 kHz Respuesta en frecuencia: 46 Hz a 24 kHz +- 2 dB en el eje
Sensibilidad: 88 dB SPL a una distancia de 1 metro en el eje. 2,83 V de voltaje de entrada.
Impedancia: nominal de 6 Ohmios, mínimo 4 Ohmios
. Cruce: Corte de frecuencia media de primer orden, corte de agudos de segundo orden, condensadores de polipropileno seleccionados e inductores de núcleo de aire se utilizan en todo el circuito.
Frecuencias de cruce 5kHz
Cableado interno: Cableado multihilar, cobre plateado, revestido de PTFE. Todas las conexiones están soldadas. Diseño de PCB de trayectoria corta. Se proporcionan conexiones para aplicaciones de un o dos cables.
Conexiones de entrada: Terminales de aleación de cobre chapado en oro mecanizadas internamente de doble cable,
capacidad máxima de potencia de 200W
en programa continuo SPL máximo 111 dB a una distancia de 1 metro.
Dimensiones: Altura Ancho Profundidad: 310 mm, 230 mm, 370 mm, Altura con el pie: 950 mm
Volumen interno: 10,5 litros
Peso: 10 kg (20 kg con reposapiés)
Teknik ve kozmetik olarak sorunsuzdur.
Demo İçin Timpani Audio'ya Bekleriz.
Teknik Özellikler
2 yollu, gerçek doğrusal fazlı, serbest alanlı, bas refleksli kabinli, ayaklı monitör
Sürücü üniteleri: 1 x 170 mm (7 inç) Wilson Benesch Tactic bas/orta frekans ünitesi ve 1 x 25 mm (1 inç) yumuşak kubbeli, elle boyanmış ipek, ultra doğrusal Wilson Benesch spesifikasyonlu tiz hoparlör.
Düşük frekanslı yükleme: Çift refleks port
Frekans aralığı: 42 Hz ve 30 kHz'de -6 dB ve 45 Hz ve 25 kHz'de -3 dB
Frekans tepkisi: Eksen üzerinde 46 Hz - 24 kHz +- 2 dB
Hassasiyet: Eksen üzerinde 1 metre mesafede 88 dB SPL. 2,83 V giriş gerilimi.
Empedans: Nominal 6 Ohm, minimum 4 Ohm
Crossover: Birinci dereceden orta frekans crossover'ı, ikinci dereceden tiz crossover'ı, tüm devrede seçilmiş polipropilen kapasitörler ve hava çekirdekli indüktörler kullanılmıştır.
Geçiş frekansları 5kHz
İç kablolama: Çok telli, gümüş kaplama bakır, PTFE kılıflı kablo demetleri. Tüm bağlantılar lehimlenmiştir. Kısa yol PCB tasarımı. Tek veya çift telli uygulamalar için bağlantılar sağlanmıştır.
Giriş bağlantıları: Çift kablolu, şirket içinde işlenmiş altın kaplama bakır alaşımlı terminaller
Kesintisiz programda 200W tepe güç kapasitesi
1 metre mesafede maksimum SPL 111 dB.
Ölçüler: YükseklikGenişlikDerinlik: 310 mm, 230 mm, 370 mm, Ayaklı yükseklik: 950 mm
İç hacim: 10,5 litre
Ağırlık: 10 kg (ayaklık ile birlikte 20 kg)
