Monrio MP11 Monoblock Amplifiers
Monrio MP11 Monoblock Amplifiers
Posted On
5.10.2021Last Update On
5.10.2021
Description
Original Description is in
English, other language texts are translations and can contain errors.
EnglishDeutschTurkish
UPC:
Monrio MP11 Monoblock Amplifiers
Condition:
New
Weight:
30.00 KGS
Minimum Purchase:
1 unit
Maximum Purchase:
1 unit
Shipping:
Calculated at Checkout
The MP11 is a powerful mono block power amplifier which offers excellent sound quality even when driving difficult loads. The 135 watts per channel output stages use selected and matched MOSFET devices to give a maximum current rating of over 25 amps allowing high power delivery into even 2 ohm loads.
A mono block form of construction has been chosen with each channel being completely independent with its own 300VA toroidal power transformer.This form of construction prevents any dynamic crosstalk and preserves a stable and detailed soundstage.
No fuses on the power supply rails. In audio amplifiers the use of conventional fuses in the supply rails causes degradation of the sound quality. Power is normally fed to the output stage from large reservoir capacitors along thick low impedance cables or printed circuit tracks.
However this power is then fed through a very thin wire in the fuse link and as the current increased this thin fuse wire heats up; its resistance rises and so destroys the benefit of using the thick cables and tracks. Instead the MP11 has no supply fuses to degrade the sound quality. Instead the current drawn by the amplifier is sensed through an isolating optocoupler whose output is fed to a protection board. In the event of excessively high currents or a DC offset voltage the protection system disconnects the mains power by energising a switching relay.
In this way the CENTO offers good sound quality without compromise and good reliability.
The circuit design of this amplifier is novel with all the stages being fully complementary and balanced. Careful design and the use of computer simulations has enabled MP11 to achieve a very wide open-loop bandwidth. The open-loop frequency response (that is without negative feed back) of this amplifier extends beyond 30 kHz compared to typical figures of about 3 kHz for most competing amplifiers. The result is a constant low level of negative feedback right across the audio band ensuring a clean, detailed, and natural quality to all the high notes.
No capacitors are used in the signal path. Their use being limited to power supply decoupling and phase compensation. The use of new DC Servo Control System ensures excellent stability with very low levels of colouration. Only the best selected components are used for MP11 amplifiers.
The circuit boards are of high grade double sided copper glass-fibre material. All resistors are 1% metal-film types whilst the capacitors are selected film types or audio grade power-supply type and all the internal wiring uses Hi-End high purity cabling.
Specifications
Output Power 135 Watts into 8 ohms
Frequency Response 2Hz-65kHz into 8 ohms
Signal-to-Noise 97dB A-weighted
Distortion THD 0,025% 1kHz into 8 ohms
Peak current Limit 17 Amps, as set by protection circuit
Input Sensitivity 0,965V for full power out, at 1 kHz
Input Impedance 49k ohms, 220pF
Damping Factor 1000
Output Impedance 0,005 ohms 1 kHz into 8 ohms
Dimension 220(w) x 115(h) x 390(d)
UPC:
Monrio MP11 Monoblock-Verstärker
Zustand:
Neu
Gewicht:
30,00 KGS
Mindestabnahme:
1 Einheit
Maximaler Kauf:
1 Einheit
Versand:
An der Kasse berechnet
Der MP11 ist ein leistungsstarker Monoblock-Leistungsverstärker, der auch bei schwierigen Lasten eine hervorragende Klangqualität bietet. Die 135-Watt-pro-Kanal-Ausgangsstufen verwenden ausgewählte und abgestimmte MOSFET-Bauelemente, um einen maximalen Nennstrom von über 25 Ampere zu erreichen, was eine hohe Leistungsabgabe an sogar 2 Ohm-Lasten ermöglicht.
Es wurde eine Monoblockbauweise gewählt, bei der jeder Kanal mit einem eigenen 300VA Ringkerntransformator völlig unabhängig ist. Diese Bauform verhindert jegliches dynamisches Übersprechen und erhält ein stabiles und detailreiches Klangbild.
Keine Sicherungen auf den Stromschienen. Bei Audioverstärkern führt die Verwendung herkömmlicher Sicherungen in den Versorgungsschienen zu einer Verschlechterung der Klangqualität. Der Ausgangsstufe wird normalerweise Strom von großen Speicherkondensatoren entlang dicker Kabel mit niedriger Impedanz oder Leiterbahnen mit gedruckter Schaltung zugeführt.
Allerdings wird dieser Strom dann durch einen sehr dünnen Draht im Sicherungseinsatz geführt und bei steigendem Strom erwärmt sich dieser dünne Sicherungsdraht; sein Widerstand steigt und zerstört so den Nutzen der Verwendung der dicken Kabel und Leiterbahnen. Stattdessen hat der MP11 keine Versorgungssicherungen, um die Klangqualität zu verschlechtern. Stattdessen wird der vom Verstärker gezogene Strom durch einen isolierenden Optokoppler erfasst, dessen Ausgang einer Schutzplatine zugeführt wird. Bei zu hohen Strömen oder einer DC-Offsetspannung trennt das Schutzsystem die Netzspannung durch Anziehen eines Schaltrelais.
Auf diese Weise bietet der CENTO eine gute Klangqualität ohne Kompromisse und eine gute Zuverlässigkeit.
Das Schaltungsdesign dieses Verstärkers ist neuartig, da alle Stufen vollständig komplementär und symmetrisch sind. Sorgfältiges Design und die Verwendung von Computersimulationen haben es MP11 ermöglicht, eine sehr große Open-Loop-Bandbreite zu erreichen. Der Open-Loop-Frequenzgang (dh ohne negative Rückkopplung) dieses Verstärkers erstreckt sich über 30 kHz im Vergleich zu typischen Werten von etwa 3 kHz für die meisten konkurrierenden Verstärker. Das Ergebnis ist ein konstant niedriges negatives Feedback im gesamten Audioband, das eine saubere, detaillierte und natürliche Qualität aller hohen Töne gewährleistet.
Im Signalpfad werden keine Kondensatoren verwendet. Ihre Verwendung beschränkt sich auf die Entkopplung der Stromversorgung und die Phasenkompensation. Der Einsatz des neuen DC Servo Control Systems sorgt für eine hervorragende Stabilität bei sehr geringer Verfärbung. Für MP11-Verstärker werden nur die besten ausgewählten Komponenten verwendet.
Die Leiterplatten sind aus hochwertigem doppelseitigem Kupfer-Glasfaser-Material. Alle Widerstände sind 1% Metallfilm-Typen, während die Kondensatoren ausgewählte Film-Typen oder Audio-Grade-Netzteile sind und die gesamte interne Verkabelung hochreine Hi-End-Kabel verwendet.
Spezifikationen
Ausgangsleistung 135 Watt an 8 Ohm
Frequenzgang 2Hz-65kHz an 8 Ohm
Signal-Rausch-Verhältnis 97 dB A-bewertet
Verzerrung THD 0,025% 1kHz an 8 Ohm
Spitzenstrombegrenzung 17 Ampere, wie von der Schutzschaltung eingestellt
Eingangsempfindlichkeit 0,965V für volle Leistung, bei 1 kHz
Eingangsimpedanz 49k Ohm, 220pF
Dämpfungsfaktor 1000
Ausgangsimpedanz 0,005 Ohm 1 kHz an 8 Ohm
Abmessungen 220 (B) x 115 (H) x 390 (T)
UPC:
Monrio MP11 Monoblok Amplifikatörler
Şart:
Yeni
Ağırlık:
30,00 KG
Minimum Satın Alma:
1 ünite
Maksimum Satın Alma:
1 ünite
Nakliye:
Ödeme sırasında hesaplanır
MP11, zorlu yükleri sürerken bile mükemmel ses kalitesi sunan güçlü bir mono blok güç amplifikatörüdür. Kanal çıkış kademeleri başına 135 watt, 2 ohm'luk yüklere bile yüksek güç dağıtımına izin veren 25 amperin üzerinde bir maksimum akım derecesi vermek için seçilmiş ve uyumlu MOSFET cihazlarını kullanır.
Her kanalın kendi 300VA toroidal güç trafosu ile tamamen bağımsız olduğu monoblok bir yapı şekli seçilmiştir. Bu yapı şekli, herhangi bir dinamik karışmayı önler ve kararlı ve ayrıntılı bir ses sahnesini korur.
Güç kaynağı raylarında sigorta yok. Ses yükselteçlerinde, besleme raylarında geleneksel sigortaların kullanılması, ses kalitesinin bozulmasına neden olur. Güç normalde, kalın düşük empedanslı kablolar veya baskılı devre yolları boyunca büyük rezervuar kapasitörlerinden çıkış aşamasına beslenir.
Ancak bu güç daha sonra sigorta bağlantısındaki çok ince bir telden beslenir ve akım arttıkça bu ince sigorta teli ısınır; direnci yükselir ve bu nedenle kalın kabloları ve rayları kullanmanın faydasını yok eder. Bunun yerine MP11'de ses kalitesini düşürecek besleme sigortası yoktur. Bunun yerine, amplifikatör tarafından çekilen akım, çıkışı bir koruma kartına beslenen yalıtkan bir optokuplör aracılığıyla algılanır. Aşırı yüksek akımlar veya bir DC ofset voltajı durumunda koruma sistemi, bir anahtarlama rölesine enerji vererek ana şebeke gücünü keser.
Bu şekilde CENTO, ödün vermeden iyi bir ses kalitesi ve iyi bir güvenilirlik sunar.
Bu amplifikatörün devre tasarımı, tüm aşamaların tamamen tamamlayıcı ve dengeli olmasıyla yenidir. Dikkatli tasarım ve bilgisayar simülasyonlarının kullanımı, MP11'in çok geniş bir açık döngü bant genişliği elde etmesini sağlamıştır. Bu amplifikatörün açık döngü frekans yanıtı (yani negatif geri besleme olmadan), çoğu rakip amplifikatör için tipik yaklaşık 3 kHz rakamlarına kıyasla 30 kHz'in ötesine uzanır. Sonuç, tüm yüksek notalarda temiz, ayrıntılı ve doğal bir kalite sağlayan ses bandı boyunca sürekli düşük düzeyde negatif geri bildirimdir.
Sinyal yolunda kapasitör kullanılmaz. Kullanımları, güç kaynağı ayırma ve faz kompanzasyonu ile sınırlıdır. Yeni DC Servo Kontrol Sisteminin kullanılması, çok düşük seviyelerde renklenme ile mükemmel stabilite sağlar. MP11 amplifikatörleri için yalnızca en iyi seçilmiş bileşenler kullanılır.
Devre kartları, yüksek dereceli çift taraflı bakır cam elyaf malzemedendir. Tüm dirençler %1 metal film türleridir, kapasitörler ise film türleri veya ses sınıfı güç kaynağı türü seçilir ve tüm dahili kablolama Hi-End yüksek saflıkta kablo kullanır.
Özellikler
Çıkış Gücü 135 Watt, 8 ohm'a
Frekans Tepkisi 2Hz-65kHz'den 8 ohm'a
Sinyal-Gürültü 97dB A ağırlıklı
Bozulma THD %0,025 1kHz, 8 ohm'a
Koruma devresi tarafından ayarlandığı gibi tepe akımı Sınırı 17 Amper
1 kHz'de tam güç çıkışı için Giriş Hassasiyeti 0,965V
Giriş Empedansı 49k ohm, 220pF
Sönümleme Faktörü 1000
Çıkış Empedansı 0,005 ohm 1 kHz - 8 ohm
Boyut 220(g) x 115(y) x 390(d)
