Sansui AU-Alpha 907DR
Sansui AU-Alpha 907DR
Posted On
13.09.2019Last Update On
13.09.2019
Description
Original Description is in
German, other language texts are translations and can contain errors.
EnglishDeutschTurkish
Absolute dream condition and also the extremely rare 240V version. 40kg live weight and a processing par excellence! At this point we leave sounding hymns of praise, We certainly do not have to convince Sansui enthusiasts any more. The Sansui AU-Alpha 907DR comes from the collector's hand, has only a very small scratch ( picture no. 10 ) and is practically in a new condition!
Power Amplifier Part
output power (20Hz - 20kHz)
Simultaneous operation with both channels, THD0.003% 6 Ohms: 190W + 190W
8 Ohm: 160 W + 160 W
THD 0.003% or less (at the time of a Output power of 20 Hz - 20 kHz, a load intensity of 8 ohms)
frequency characteristic DC-300kHz and +0 -3 dB (at 1W power)
cross modulation distortion 0.003% or less (at the time of an 8-ohm load intensity)
dumping factor 150 (8 ohms)
Input Sensitivity / Impedance 1 V / 5 kOhm (1 kHz)
SN ratio 120 dB or more (A-Network)
Dynamic power 6 Ohms: 310W
4 Ohms: 390W
2 Ohms: 580W
TIM Distortion (SAWTOOTH) Below a measurement limit
Rise speed 200 V /microsecondrise time 0.5 microseconds
Pre part
input sensitivity / impedance
(1 kHz) Phono-man month: 2.5 mV / 47 kOhm
Phono MC: 300 microvolts / 100 ohms
CD, Tuner, Line, Tape / DAT1-2-3: 150 mV /, 20 kOhm
Maximum permissible phono input MM (THD 0.01%): 250 mV
MC (THD 0.1%): 25 mV
The frequency characteristics (1 W) Phono-Man-Month: 20 Hz - 20 kHz, x 0.2 dB
CD, tuner, line, tape / DAT-1, 2 and 3: DC-300Hz and +0-3 dB
SN Ratio (A-Network) Phono-Man-Month: 90 dB or more
Phono MC: 75dB or more
CD, Tuner, Line, Tape / DAT-1, 2-3: 110dB or more
Sound control The maximum BASS variation: 5 dB (50 Hz)
The maximum TREBLE variation: )
subsonic filter 16 Hz (-3 dB), 6 dB / Oct
Volume 50Hz: + 4dB
10 kHz: + 3 dB
Absoluter Traumzustand und zudem die extrem seltene 240V Version. 40kg Lebendgewicht und eine Verarbeitung par excellence! Klangliche Lobeshymnen lassen wir an dieser Stelle, Sansui Enthusiasten müssen wir sicherlich nicht mehr überzeugen. Der Sansui AU-Alpha 907DR stammt aus Sammlerhand, hat lediglich ein ganz kleines Kratzerchen ( Bild Nr. 10 ) und befindet sich quasi im Neuzustand!
Leistungsverstärkerteil
Ausgangsleistung (20Hz - 20kHz)
Gleichzeitiger Betrieb mit beiden Kanälen, THD0.003% 6 Ohm: 190W + 190W
8 Ohm: 160 W + 160 W
THD 0,003% oder weniger (zum Zeitpunkt einer Ausgangsleistung von 20 Hz - 20 kHz, einer Lastintensität von 8 Ohm)
Frequenzcharakteristik DC-300kHz und +0 -3 dB (bei 1W Leistung)
Kreuzmodulationsverzerrung 0,003% oder weniger (zum Zeitpunkt einer 8-Ohm-Lastintensität)
Dumping-Faktor 150 (8 Ohm)
Eingangsempfindlichkeit / Impedanz 1 V / 5 kOhm (1 kHz)
SN-Verhältnis 120 dB oder mehr (A-Netzwerk)
Dynamische Leistung 6 Ohm: 310W
4 Ohm: 390W
2 Ohm: 580W
TIM-Verzerrung (SAWTOOTH) Unterhalb eines Messgrenzwerts
Anstiegsgeschwindigkeit 200 V / Mikrosekunde
Anstiegszeit 0,5 Mikrosekunden
Pre part
Eingangsempfindlichkeit / Impedanz
(1 kHz) Phono-Mann-Monat: 2,5 mV / 47 kOhm
Phono MC: 300 Mikrovolt / 100 Ohm
CD, Tuner, Line, Tape / DAT1-2-3: 150 mV /, 20 kOhm
Maximal zulässiger Phono-Eingang MM (THD 0,01%): 250 mV
MC (THD 0,1%): 25 mV
die Frequenzcharakteristik (1 W) Phono-Mann-Monat: 20 Hz - 20 kHz, ± 0,2 dB
CD, Tuner, Line, Tape / DAT-1, 2 und 3: DC-300Hz und +0-3 dB
SN-Verhältnis (A-Netzwerk) Phono-Mann-Monat: 90 dB oder mehr
Phono MC: 75dB oder mehr
CD, Tuner, Line, Tape / DAT-1, 2-3: 110dB oder mehr
Klangregelung Die maximale BASS-Variation: ± 5 dB (50 Hz)
Die maximale TREBLE-Variation: ± 5 dB (15 kHz)
Unterschallfilter 16 Hz (-3 dB), 6 dB / Okt
Lautstärke 50Hz: + 4dB
10 kHz: + 3 dB
Mutlak rüya durum ve aynı zamanda son derece nadir 240V sürümü. 40kg canlı ağırlık ve bir işleme par mükemmellik! Bu noktada biz övgü sondaj ilahiler bırakın, biz kesinlikle artık Sansui meraklıları ikna etmek zorunda değildir. Sansui AU-Alpha 907DR koleksiyoncu elinden geliyor, sadece çok küçük bir çizik var (resim no. 10 ) ve pratikte yeni bir durumda!
Güç Amplifikatörü Part
çıkış gücü (20Hz - 20kHz)
Her iki kanalla da eşzamanlı çalışma, THD0.003%6 Ohms: 190W + 190W
8 Ohm: 160
W
THD %0,003 veya daha az (bir anda) 20 Hz - 20 kHz çıkış gücü, 8 ohms)frekans karakteristik DC-300kHz ve +0 -3 dB (1W güç)
çapraz modülasyon distorsiyon bozulma 0
003% veya daha az (8-ohm yük yoğunluğu sırasında)
damping faktörü 150 (8 ohms) bir yük yoğunluğu
Giriş Hassasiyeti / Empedans 1 V / 5 kOhm (1 kHz)
SN oranı 120 dB veya daha fazla (A-Network)
Dinamik güç 6 Ohms: 310W
4 Ohms: 390W
2 Ohms: 580W
Tİm Distorsiyon (SAWTOOTH) Ölçüm limitinin altında
Yükselme hızı 200 V /mikrosaniyerise time 0.5 microseconds
Pre part
input hassasiyeti / empedans(1 kHz) Fono adam ay: 2.5 mV / 47 kOhm
Fono MC: 300 mikrovolt / 100 ohms
CD, Tuner, Line, Teyp / DAT1-2-3: 150 mV /, 20 kOhm
Maksimum izin verilen fono girişi MM (THD %0.01):250 mV
MC (THD %0.1): 25mV
Frekans özellikleri (1 W) Fono-Adam-Ay: 20 Hz - 20 kHz, x 0.2 dB
CD, tuner, hat, bant / DAT-1, 2 ve 3: DC-300-000-0 dB
SN Oranı (A-Network) Fono-Man-Month: 90 dB veya daha fazla
Phono MC: 75dB veya daha fazla
CD, Tuner, Line, Teyp / DAT-1, 2-3: 110dB veya daha fazla
Ses kontrolü Maksimum BAS varyasyonu: 5 dB (50 Hz)
Maksimum TREBLE varyasyonu: )
subsonic filtre 16 Hz (-3 dB), 6 dB / Ekim
Hacim 50Hz: + 4dB
10 kHz: + 3 dB
