Edge NL1.1 Signature Monoblocks
Edge Electronics NL1.1
19 görüntüleme bu ay
İlan Tarihi 25.04.2025
Son Güncelleme 25.04.2025 Edge Electronics NL1.1
Edge Electronics NL1.1 Edge Electronics NL1.1 Edge Electronics NL1.1 Edge Electronics NL1.1 Edge Electronics NL1.1 Edge Electronics NL1.1
Açıklama Orjinal Açıklama İngilizce, diğer lisan metinleri çeviridir ve hata içerebilir. İngilizceAlmancaİspanyolcaTürkçe Very good condition, just a few light marks. With original packaging.

The NL Signature One.1 monoblocks are the ultimate amplifier in the line of NL amplifiers. While retaining the overall character of the smaller NL amplifiers - the speed, smoothness and micro-dynamics - the NL is just so much better in all respects: the added power allows notes, at all frequencies, to explode within the force and passion that the music is demanding. There is much more authority in each note, you can just hear when the musician wanted to start the note, the emotion they wanted in the note, and exactly when they wanted the note to end. Essentially, it cleans up the many layered window between musician and listener.



The NL series amplifiers all use the same sized chassis and only differ in their outward aesthetic design and, of course, their internal electronics. The heatsinks on NL Signature One are wavy in form, unlike its siblings. All NL series amplifiers run only slightly warm to the touch and contain no sharp edges, which makes them user, family, placement, and summertime friendly.



"The EDGE NL Signature One.1 is the quintessential expression of technology serving music.  Using EDGE proprietary Laser Biased Control circuitry this amplifier redefines "linear".   Massively constructed and well endowed throughout, it becomes "invisible" in all situations.  Use this one for your most demanding audio reproduction requirements."



RECOMMENDED USAGE

The NL Signature Ones are excellent for systems that either: need or want a lot of power, are too bright, the listener would like to use tubes but cannot or does not want to deal with tube's negative environmental issues (heat, maintenance, foot-print), or those systems that do not have enough PRaT (pacing, rhythm and timing).



TECHNICAL HIGHLIGHTS

Dual Chassis Monoblock design

with four 1500 VA Toroidal transformers (two per chassis)

Each transformer operates at 96% efficiency. Regulation equals 4%

Laser Source Front Panel Illumination (one per chassis)

Bias Circuit One 630 nm Bias Laser per channel

Output Circuit: 64 NPN Bipolar Transistors, 32 per channel

Power Supply Filtration: 320,000 �F: 16 x 10,000 �F per channel

RMS Power Output: 400 Watts per channel @ 8 Ohms

800 Watts per channel @ 4 Ohms

Total Harmonic Distortion: <0.01%

Transient Intermodulation Distortion: <0.01%

Slew Rate: 120 Volts per microsecond

Bandwidth: 1Hz-150KHz , + 0 -2.5dB

Input Impedance: 30,000 Ohms

Input Type: RCA

Output Impedance: 0.015 Ohms

Constant Current Capability: 83.32 Amps, 41.67 per independent channel

Dimensions: 19.0" Deep x 15.0" Wide x 9.0" High

Weight: 230 (115 Pounds each)
